Ref: TS 91V5 | TS 92V5

IP68 MEMS Capacitive Tilt Sensors - Uni or biaxial - Stainless steel

  • Range: ±15°, ±90°
  • Uniaxial / Biaxial
  • 4 / 8 Wire System
  • DC Response
  • High Resolution
  • Low Temperature Coefficient of Bias
  • Excellent Long-Term
  • Bias Stability
  • Wide Temperature Range (-40 to 120°C)
  • High Shock Limit (500g)
  • Protection Class IP68
  • Stainless Steel Housing (192g)

Download the product sheet

?

Presentation

TS-91V5 and TS-92V5 inclination sensors feature an analog voltage output and are available in two versions, uniaxial and biaxial. Biaxial inclination sensors contain two independent MEMS sensors oriented at 90° to each other to allow perpendicular tilt measurement. TS-91V5 and TS-92V5 feature a rugged stainless steel IP68 housing (192 g), which provides case isolation against ground loops. The sensor sensitivity and bias is extremely stable over a wide temperature range from -40°C to +120°C.

The inclination sensors TS-91V5 and TS-92V5 can be powered using a 6-36 VDC supply, where the output is independent of the supply. Both tilt sensors can withstand shocks as 5000g and feature a stainless steel housing (192 g) with an integral cable. The sensors can be configured with a 4-20 mA current output as an option, by a temperature range from -20 to +70°C.

Applications

  • Crane Safety Systems
  • Building Construction Machines
  • Solar Array Tracking Systems
  • Ship’s Navigation Posture Measurement
  • Flap Bridge Monitoring
  • Track Alignment & Maintenance
  • Wheel Alignment
  • Truck Chassis Levelling
  • Machine Tool Angle Positioning
Technologie
MEMS capacitive
Number of Axis
1 Axis, 2 Axis
Etendue de mesure
15 / 90 °
Résolution
0.001° - 0.01°
Application
OEM, Sbmersible
Nonlinearity (% FS)
± 1 %
Sortie analogique
analog (Voltage)
Analog output signal
± 5 VDC
Digital output signal
none
Tension d'alimentation
10 Vcc
Protection Class
IP68
Housing
Steel

Cable and connectors

Acquisition system
