Ref: JMHI-100 / JMI-200
Analog MEMS precision inclinometer - 1 or 2 axis | ±14.5 to 90°
- ±14.5°, ±30°, ±60° and ±90° ranges
- Robust and Rugged Enclosure
- Single and Dual Axis Models Available
- Low-Cost MEMS Technology
- RoHS Compliant
- Filtering Available
- Single Power Input
- 0-5 VDC Output
- Temperature Sensor Option Available
- IP67 Seal
?
Presentation
The JMI-100/200 series is available in single (JMI-100) and dual (JMI-200) axis configurations. This presents a robust and rugged design for industrial use.
Applications
- Industrial Automation & Control
- Construction & Agricultural Equipment
- Solar Tracking
- Mobile Cranes
- Platform Leveling/Positioning
- Mobile Radar Equipment
- Railway Track Alignment & Maintenance
- Technologie
- MEMS capacitive
- Number of Axis
- 1 Axis, 2 Axis
- Etendue de mesure
- 14.5 / 30 / 90 / 60 °
- Résolution
- 0.001° - 0.01°
- Bande passante (-3 dB)
- 5 Hz
- Application
- OEM
- Nonlinearity (% FS)
- ± 0.06 %
- Nonrepeatability
- 0.004 % FS
- Sortie analogique
- analog (Voltage), analog (Current)
- Analog output signal
- 0-5 VDC, ± 5 VDC, 4-20 mA
- Digital output signal
- none
- Tension d'alimentation
- 10 Vcc
- Température de fonctionnement
- -40 to 85 °C
- Connecteur
- SUBD9 or M12
- Protection Class
- IP67
- Housing
- Aluminium
Ruby-JMHI.pdf
Ruby-OD.pdf
Ordering information
- JMI-100-S-14.5: ±14.5°
- JMI-100-S-30: ±30.0°
- JMI-100-S-90: ±90.0°
- JMI-100-D-14.5: ±14.5°
- JMI-100-D-30: ±30.0°
- JMI-100-D-90: ±90.0°
- JMI-100-L-14.5: ±14.5°
- JMI-100-L-30: ±30.0°
- JMI-100-L-90: ±90.0°
- Cable and connectors
- mounting plate
- display
- Data Acquisition systems
